XR530 - RFID編碼門禁讀卡器
Card access control with RFID encoding
RFID sensor with 16 million codes
Lock control and two alarm levels
Programmable code through auto-learning (no software or PC)
．Switching cycle: B10 = 1 million
．Max activation distance: XR 530P up to 25 mm - XR 550P up to 50 mm
．Contact/diagnostics: 1 x 1.8A PNP timed 5s/2 x 200m APNP
．Alarm 1 (120s failure to close) and 2 (30s breaking open)
．Duration of alarms editable upon request (XR530P, P1 ... P10)
．Detection encoding: 16 million
．Indicator: LED indicates code recognition
．Optional erasing card to reassign new codes
．Encoding of geographic location: (base + E1 to E10) Reset : automatic
．Attachment: 4 tamper-proof M4 screws (in base option: BH4)
．Mounting position: 2 (double wall brackets)
．Material: PA6
．Electrical Connection: 3, 6, 12m (UL2464 PVC)
．Sealing: IP 67
．Temperature: -25 °C to +70 °C.
．Marking: pad printing + serial number for traceability
．Option: badge nail, screw, plate screw, key chain, card ... etc.
．Application example: access to luxury showcases with lock control
