MASSIMOTTO X5 - 單門或雙翼門的安全開關
Position control for doors / casings on hazardous machinery
Contactless encoded electronic sensor with relay
Category 3 total safety management without an external controller
Contactless encoded electronic sensor with relay
Category 3 total safety management without an external controller
Suitable for groove profiles and single or double doors
.Level of performance without an external controller: PL = d
.Level of performance with AWAX controller: up to PL = e
.Safety category without an external controller: 3
.Safety Integrity Level: SIL 2
.Cycle before dangerous failure: B10d = 2,000,000 at 2A
.Max. activation distance: 8 mm, 3 mm hysteresis
.Safety contacts/diagnostics: 2 x NO 2A/48V redundant / 1 x PNP 250mA (X5) or 1xNF (X5.2) auxiliary
.Detection encoding: mono-code inviolable
.Indicator: LED indicates code recognition
.Reset: automatic (SR version) or Manual (AR version)
.Attachment: 4 tamper-proof M4 screws (optional ref: BH4). Suitable for grooved profiles. Screw caps provided.
.Mounting position: 1
.Material: Polycarbonate
.Electrical connection: 1 M12 connector (X5 version) or 2 M12 connectors (X5.2 version for instant serial connection)
.Water resistance: IP 67/68
.Temperature: -25°C to +60°C
.Marking: screen printed + serial no. for traceability
.Certification: TÜV Rheinland 01/205/5238/12
.License Test Mark 968/EL 214.01/12
.Level of performance with AWAX controller: up to PL = e
.Safety category without an external controller: 3
.Safety Integrity Level: SIL 2
.Cycle before dangerous failure: B10d = 2,000,000 at 2A
.Max. activation distance: 8 mm, 3 mm hysteresis
.Safety contacts/diagnostics: 2 x NO 2A/48V redundant / 1 x PNP 250mA (X5) or 1xNF (X5.2) auxiliary
.Detection encoding: mono-code inviolable
.Indicator: LED indicates code recognition
.Reset: automatic (SR version) or Manual (AR version)
.Attachment: 4 tamper-proof M4 screws (optional ref: BH4). Suitable for grooved profiles. Screw caps provided.
.Mounting position: 1
.Material: Polycarbonate
.Electrical connection: 1 M12 connector (X5 version) or 2 M12 connectors (X5.2 version for instant serial connection)
.Water resistance: IP 67/68
.Temperature: -25°C to +60°C
.Marking: screen printed + serial no. for traceability
.Certification: TÜV Rheinland 01/205/5238/12
.License Test Mark 968/EL 214.01/12
