OPTO2S-微型安全開關
Position control for doors / casings on hazardous machinery
Contactless encoded electronic sensor with relay
Category 3 total safety management without an external controller
Contactless encoded electronic sensor with relay
Category 3 total safety management without an external controller
12V version for embedded applications
.Level of performance without an external controller: PL = c
.Level of performance with AWAX controller: up to PL = e
.Safety category without an external controller: 1
.Cycle before dangerous failure: B10d = 2,000,000 at 50mA
.Max. activation distance: 10 mm, 2 mm hysteresis
.Safety contacts: 2 x NO 250 mA/48V redundant
.Detection encoding: mono-code inviolable
.Indicator: LED indicates code recognition
.Reset: automatic
.Attachment: 4 tamper-proof M3 screws (optional ref: BH3)
.Mounting position: 2 (double wall brackets)
.Material: PA6
.Electrical Connection: 3, 6, 12m cable (UL2464 PVC)
.Water resistance: IP 68
.Temperature: -20°C to +60°C
.Marking: pad printing + serial no. for traceability
.Level of performance with AWAX controller: up to PL = e
.Safety category without an external controller: 1
.Cycle before dangerous failure: B10d = 2,000,000 at 50mA
.Max. activation distance: 10 mm, 2 mm hysteresis
.Safety contacts: 2 x NO 250 mA/48V redundant
.Detection encoding: mono-code inviolable
.Indicator: LED indicates code recognition
.Reset: automatic
.Attachment: 4 tamper-proof M3 screws (optional ref: BH3)
.Mounting position: 2 (double wall brackets)
.Material: PA6
.Electrical Connection: 3, 6, 12m cable (UL2464 PVC)
.Water resistance: IP 68
.Temperature: -20°C to +60°C
.Marking: pad printing + serial no. for traceability
